Brand Name: | MobyData |
Model Number: | M63 |
MOQ: | 1pcs |
Price: | TBD |
Delivery Time: | 7wks days < MOQ500 |
Payment Terms: | T/T |
Authorized decoding libraries by Datalogic
Application Area
General purpose professional PDA equipment
Optional Accessory
Technical Specifications | |
OS | Android 14 |
CPU | Octa Core, 2.0GHz; 2XA75+6xA55 or 4xA53+4xA53 |
MEMORY | RAM:2 GB/4 GB; Flash:32 GB/64 GB |
Physical Specifications | |
Weight | 279g(With battery) |
Dimension | 165.86mmx67mmx19.22mm |
Keypad | 20-key numeric keyboard Left/right scan Back, home, toggle touch keys |
Main Parameters | |
LCD | 4.0 inch, 800*480 |
TP | IPS GFF capacitive screen, multi-touch |
Extend Slot | SIM card slot: Single card, Nano SIM*1+TF*1 |
SD card slot: MicroSD, up to 256GB | |
Main camera | Auto focus 8Mega, flash |
Front camera | Fixed focal length, 5Mega (option) |
Power and Charging | |
USB | USB 2.0 Type-C charging data transmission |
Adapter | 5V2A 100~240V AC 50/60HZ, Plug: National standard |
Battery | 5000 mAh min, Replaceable |
Charging | <3.5h |
Operation | >30 hours |
Battery life | 500 cycle> 80% |
Sensors | |
Gravity sensor | Option |
Proximity Sensor | Option |
Photosensitive sensor | Option |
Hall Sensor | Option |
status lamp | Yes |
Voice | |
Speaker | Min 100db |
Receiver | Option |
Mic | Double Mic with Noise Reduction |
Environment | |
IP | IP65 |
Drop | 1.5m steel floor fell 30 times, 1.8m steel floor fell 60 times (with silicone sleeve) |
Tumble | 0.5m steel plate falls 2000 times, 0.5m steel plate roller 3000 times (with silicone sleeve) |
Storage Temperature | -30C to 70C |
Operation Temperature | -25°C ~ +55°C |
Humidity | 5%-95% non-condensing |
Charging Temp | 0°C -35°C |
ESD | 8K/15K |
Data Collection | |
Engine | E31XX/E34XX |
Green Spot | Option |
Symbologies | 1D Codes /2D Codes /Postal Codes |
Wireless | |
Bluetooth | BLE V5.0 |
WLAN | 802.11.a/b/g/n/ac WiFi dual band radio; IPv4; IPv6 |
GPS | GPS/Glonass/Galileo/Beidou,Assisted GPS |
NFC | Option |
WWAN | 2G/3G/4G full Netcom |
VOLTE | Yes |
CA | LTE CAT6, CA B1/3/7/40/41,Downlink 300Mbps |
Gift Box | |
Device, QSG, Adapter, USB cable,Battery |
Optional Accessory | |
Single host and battery charger, 4-slot device charger, 4 battery charger, Spare battery, silicon rubber case, wrist strap, Shoulder belt |
Warranty | |
Labor warranty for parts for 12 months |
FAQ
1. Are you a manufacturer?
Yes, we are. As a professional manufacturer specializing in barcode scanners and PDA terminals, we possess deep expertise in industrial design, mainboard development, product testing, and full-scale production. We enforce rigorous quality control across all operational processes, ensuring our products consistently meet the highest industry standards.
2. Will you provide free SDK for me?
Certainly
3. What is the warranty period for your products?
Our products come with a Min. 12-month warranty (starting from the date of shipment), excluding parts that are consumable.
4. What is your minimum order quantity (MOQ)?
The standard MOQ for stock products is 1 unit. For OEM/ODM projects, please provide your detailed requirements (e.g., customization scope, specifications), and we will advise the corresponding MOQ based on your needs.
5. Is it possible to obtain a free sample?
While we do not offer free samples, we welcome you to purchase a single sample unit for testing and evaluation.
6. Do you accept payments via PayPal?
No
7. How long is the delivery time?
For sample orders, we usually dispatch within 2-3 working days after payment has been confirmed. For bulk orders, the lead time may vary from 1 to 4 weeks, depending on the exact quantity required.
8. What shipping methods do you use for delivery?
DHL, UPS, TNT, FEDEX, Aramex, EMS, and E-packing, or arrange the collection of goods yourself.
9. Could you describe your after-sales service?
a. All products come with a minimum 12-month warranty (extendable for certain
components), covering manufacturing defects and non-consumable parts.
b. We maintain a large inventory of genuine spare parts to ensure prompt replacement or repair of service requests, minimizing downtime for your operations.
c. Our team of certified engineers provides 24/7 online support (via phone, email, or remote access) to address troubleshooting, software updates, and operational guidance.
d. For complex issues, we can offer on-site service support (subject to regional availability) and customized maintenance plans to meet your specific needs.
